Mansten Panel


Product Features

  • Standard product is sold with ON/OFF application.
  • Voltage Range: 100~305 VAC, 142~431 VDC for continuous use; 320 VAC for 24 Hrs; 360 VAC for 1 Hr.
  • 1-10 V Dim, DALI Driver, and Emergency Kit can be applied.
  • High transparency opal diffuser used.



BodyElectrostatic Powder Coated Aluminum Injection Body
LEDHigh Efficient Midpower
Beam Angle Options130°
DiffuserOpal Diffuser
Inner Cutting SizeSurface Mounted; Pendant
Color Rendering Index (CRI)> 80
PF (Power Factor)> 90
Operating Voltage220~240 Volt AC
LED Life60.000 Hours
Body Color RAL CodeRAL 9005 - RAL 9016
Total Power of Luminaire25 Watt
Luminous of Luminaire2.522 Lm
Efficiency of Luminairemin 97 Lm/W (6500 K)
Protection Mark (IP) IP 44
Warranty5 Years
Mansten Panel
More Options

More Options

 Total Power of LuminaireLuminous of LEDLuminous of LuminaireEfficiency of LuminaireDimensions (mm)Package AmountWeight (kg)
20 Watt19 W2.063 Lm1.650 Lmmin 97 Lm/W300x300x9081,90
Visual: 25 Watt26 W3.153 Lm2.522 Lmmin 97 Lm/W300x600x9042,25
35 Watt35 W4.126 Lm3.395 Lmmin 97 Lm/W600x600x9024,25
55 Watt54 W6.526 Lm5.221 Lmmin 97 Lm/W600x600x9024,25



Body ColorWhite, Black, Optional RAL
Light Color (Kelvin)3000, 4000, 6500
Application AreasOffices, Hotels, Stores, Hospitals, Shopping Centers, Restaurants
Technical Drawing

Technical Drawing for Mansten Panel
